Factory direct sale 699 6900 6901 6902 6903 6904 deep groove ball bearing
The Factory Direct Sale 699 6900 6901 6902 6903 and 6904 Deep Groove Ball Bearing is a value this is anybody amazing for top-quality bearings which will withstand probably the most challenging conditions. These bearings are design...
- Overview
- Related Products
CIXIHOTO
The Factory Direct Sale 699 6900 6901 6902 6903 and 6904 Deep Groove Ball Bearing is a value this is anybody amazing for top-quality bearings which will withstand probably the most challenging conditions. These bearings are designed due to the degree greatest of accuracy and are engineered to deal with extreme conditions and harsh surroundings. The smooth and procedure this is dependable of bearings might help lessen your gear downtime while upping your efficiency.
CIXIHOTO is simply a brand name this is trusted the industry and their deep groove ball bearings are not any exclusion. The bearings are made with premium materials that can deliver performance this is maximum and they're developed to final. The construction durable lasting procedure and can assist expand living of your respective equipment.
These bearings can be utilized in a variety of applications such as automotive commercial equipment gear plus much more. They may be created to resist use tear exorbitant high vibrations and extreme conditions. There is a load-bearing high helping to cause them to well suited for heavy-duty applications.
The 699 6900 6901 6902 6903 and 6904 Groove deep Ball by CIXIHOTO will come in a lot of different sizes to suit your requirements. They are typically an easy task to install and every bearing is housed in an enclosure durable safeguards it from dirt debris and other contaminants.
One of the better reasons behind these bearings may be the affordability. Being a purchase factory-direct you can acquire them at a cost this is unbeatable. You are going to lower your expenses on your own task own without to sacrifice performance or quality. Plus, as a result of the supported by a guarantee you can easily feel confident in your purchase.
The Factory Direct Sale 699 6900 6901 6902 6903 and 6904 Groove deep Ball by CIXIHOTO is a good option if you're finding a relatively inexpensive top-quality and durable band of bearings. These bearings are created to satisfy with all the requirements associated with the variety of companies and could enable you to have the work working quickly and effortlessly. Therefore, whether you are an expert or perhaps a DIY enthusiast these bearings are a definite must-have for these devices kit
2. OD Size: 3mm~200mm
3. ID Size: 0.5mm~180mm
4. Certification: ISO9001, SGS, CTI, ROHS
Product Name | DEEP GROOVE BALL BEARING |
Material | Chrome Steel, Carbon steel, Stainless steel |
Series | Series 6000, 6200, 6300, 6400, 6900, 6800, etc |
Clearance | C2, C0, C3, C4, C5 |
Precision grade | P0, P6, P5, P4, P2 or ABEC-1, ABEC-3, ABEC-5, ABEC-7, ABEC-9 |
Reference Standard | DIN620(Germany), ANSI(America), ISO, INA, NTN, NSK, etc |
Delivery Date | Normally ready goods and stock within 7 days |
Used | Electric machine, motocycle, ATM, fan, conveyor, cement mixer etc |
Item | 699 ZZ 2RS |
Size | ID9x OD20 x W6mm, 0.0082kg |
Radius (min. r) | 0.3mm/0.012 inch |
Basic load Rating KN | Dynamic 2.48 C Static 1.08 C。 |
Ball complement | NO 9 Size 2.381mm |
Max Runout Speed | 27000 r/min with grease 34000 r/min with oil |
Item | 6900 open ZZ 2RS |
Size | ID10 x OD22 x W6mm, 0.009kg |
Radius (min. r) | 0.5mm/0.020 inch |
Basic load Rating KN | Dynamic 3.30 C Static 1.40 C。 |
Ball complement | NO 9 Size 3.175mm |
Max Runout Speed | 25000 r/min with grease 32000 r/min with oil |
Item | 6901 open ZZ 2RS |
Size | ID12 x OD24 x W6mm, 0.011kg |
Radius (min. r) | 0.5mm/0.020 inch |
Basic load Rating KN | Dynamic 3.38 C Static 1.48 C。 |
Ball complement | NO 10 Size 3.175mm |
Max Runout Speed | 20000 r/min with grease 28000 r/min with oil |
Item | 6902 open ZZ 2RS |
Size | ID15 x OD28 x W7mm, 0.016kg |
Radius (min. r) | 0.5mm/0.020 inch |
Basic load Rating KN | Dynamic 4.00 C Static 2.02 C。 |
Ball complement | NO 10 Size 3.969mm |
Max Runout Speed | 19000 r/min with grease 26000 r/min with oil |
Item | 6903 open ZZ 2RS |
Size | ID17 x OD30 x W7mm, 0.018kg |
Radius (min. r) | 0.5mm/0.020 inch |
Basic load Rating KN | Dynamic 4.30 C Static 2.32 C。 |
Ball complement | NO 11 Size 3.969mm |
Max Runout Speed | 18000 r/min with grease 24000 r/min with oil |
Item | 6904 open ZZ 2RS |
Size | ID20 x OD37 x W9mm, 0.036kg |
Radius (min. r) | 0.5mm/0.020 inch |
Basic load Rating KN | Dynamic 6.55 C Static 3.60 C。 |
Ball complement | NO 11 Size 4.763mm |
Max Runout Speed | 17000 r/min with grease 22000 r/min with oil |
Warehouse
Inspection Dept.
A: We are factory. We support video see factory in this serious condition.
Q: How long is your delivery time?
A: Generally it is 1~3 days if the goods are in stock. or it is 7-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment?
A: Payment<=1000usd, 100="">=1000USD, 30% T/T in advance, balance before shippment.
