T9A.T10A Hot rolled ,cold drawn steel wire
CIXIHOTO
T9A T10A Hot rolled, cold drawn steel wire is just an item this is certainly top-quality of this includes an amount of applications across different companies. It is actually understood because of its robustness, malleability, and d...
- Overview
- Related Products
CIXIHOTO
T9A T10A Hot rolled, cold drawn steel wire is just an item this is certainly top-quality of this includes an amount of applications across different companies. It is actually understood because of its robustness, malleability, and durability that makes it a choice this is certainly perfect applications that are critical
The T9A T10A metal wire is manufactured out of premium quality metal materials via a hot-rolling and procedure this is certainly cold-drawing. CIXIHOTO this procedure involves moving the metal via a number of rollers, which deform it into the desired form whilst it continues to be hot. The procedure that is cold-drawing brings the metal by means of a die, further boosting its strength, tensile properties, and precision that is dimensional
The metal that is ensuing is t9A T10A established fact due to the exceptional power and corrosion-resistant properties. That is an option that is ideal used in many applications, including car, construction, and manufacturing companies. The metal cable is perfect for used in making springs, screws, bolts, along with other elements being need that is critical power and opposition to corrosion
The T9A T10A metal wire comes in various diameters, which range from 0.2mm to 12mm, rendering it well suited for used in both little and applications which are big. The metal cable comes into play various lengths, including coils and cut that is directly, relating to your unique requirements
CIXIHOTO's T9A T10A steel wire is created to meet the industry quality requirements that could be greatest. It’s tested rigorously to make certain that it meets all the needed technical and properties which is often real as tensile power, elongation, and hardness. It will help to ensure that the steel wire satisfies all of the specs which are needed additionally ensuring it's safe to be utilized in critical applications
High Carbon Spring Steel Wire
1. Diameter range: 0.1mm-20mm
2. Main application: making spring, mattress, wire rope
3. Standard: GB4357, DIN17223, JIS G 3521
Standard:DIN17223
High Carbon Spring Steel Wire | |||
wire diametermm | Tensile Strength N/mm² | ||
Grade A | Grade B | Grade C | |
0.30 |
| 2370-2650 |
|
0.40 |
| 2270-2550 |
|
0.50 |
| 2200-2470 |
|
0.60 |
| 2140-2400 |
|
0.70 |
| 2090-2350 |
|
0.80 |
| 2050-2300 |
|
1.00 | 1720-1970 | 1980-2220 |
|
1.20 | 1670-1910 | 1920-2160 |
|
1.40 | 1620-1860 | 1870-2100 |
|
1.60 | 1590-1820 | 1830-2050 |
|
1.80 | 1500-1780 | 1790-2010 |
|
2.00 | 1520-1750 | 1760-1970 | 1980-2200 |
3.00 | 1410-1620 | 1630-1830 | 1840-2040 |
4.00 | 1320-1520 | 1530-1730 | 1740-1930 |
5.00 | 1260-1450 | 1460-1650 | 1660-1840 |
6.00 | 1210-1390 | 1400-1580 | 1590-1770 |
7.00 | 1160-1340 | 1350-1530 | 1540-1710 |
8.00 | 1120-1300 | 1310-1480 | 1490-1660 |
9.00 | 1090-1260 | 1270-1440 | 1450-1610 |
10.00 | 1060-1230 | 1240-1400 | 1410-1570 |
11.00 |
| 1210-1370 | 1380-1530 |
12.00 |
| 1180-1340 | 1350-1500 |
13.00 |
| 1160-1310 | 1320-1470 |
.Delivery condition
(1) Delivery time: In 20 days or according to client's requires
(2) Trade terms: EXW/FOB/CIF etc
(3) Payments: T/T or L/C
(4) Port: Ningbo or Shanghai
(5) MOQ: 100kgs or at customer's demands
(6) Packing: seaworthy packing, wooden case, carton, woven bag or at client's requires
