WHOLESALE FAST SPEED LOW FRICTION SINGLE ROW BALL Bearing R6 R4 R8 OEM BALL BEARING
Product Description
1. Grade: ABEC-1,ABEC-3,ABEC-5,ABEC-7,ABEC-92. OD Size: 3mm~200mm3. ID Size: 0.5mm~180mm4. Certification: ISO9001, SGS, CTI, ROHS
Product NameDEEP GROOVE BALL BEARINGMaterialChrome Steel ,Carbon steel,St...
- Overview
- Related Products
Product Description
1. Grade: ABEC-1,ABEC-3,ABEC-5,ABEC-7,ABEC-9
2. OD Size: 3mm~200mm
3. ID Size: 0.5mm~180mm
4. Certification: ISO9001, SGS, CTI, ROHS
Product Name | DEEP GROOVE BALL BEARING |
Material | Chrome Steel ,Carbon steel,Stainless steel |
Series | Series 6000,6200,6300,6400 ,6900,6800, etc. |
Clearance | C2,C0,C3,C4,C5 |
Precision grade | P0,P6,P5,P4,P2 or ABEC-1,ABEC-3,ABEC-5,ABEC-7,ABEC-9 |
Reference Standard | DIN620(Germany), ANSI(America),ISO,INA, NTN, NSK,etc. |
Delivery Date | Normally ready goods and stock within 7 days |
Used | Electric machine, motocycle,ATM,fan,conveyor, cement mixer etc |
Item | R4 open ZZ 2RS |
Size | ID6.35 x OD15.875 x W4.98mm, |
Radius (min.r) | 0.3mm/0.012 inch |
Basic load Rating KN | Dynamic 0.742 C Static 0.342 C。 |
Ball complement | NO 8 Size 2.381mm |
Max Runout Speed |
Item | R6 open ZZ 2RS |
Size | ID9.525 x OD22.225x W7.14mm, |
Radius (min.r) | 0.4mm/0.016 inch |
Basic load Rating KN | Dynamic 2.556 C Static 1.351 C。 |
Ball complement | NO 7 Size 3.969mm |
Max Runout Speed |
Item | R8 open ZZ 2RS |
Size | ID12.7 x OD28.575 x W7.94mm |
Radius (min.r) | 0.4mm/0.016 inch |
Basic load Rating KN | Dynamic 3.912 C 5CStatic 2.245 C。 |
Ball complement | NO 8 Size 4.763mm |
Max Runout Speed |
The exihibition
Our Company
Factory---one-stop productions
Workshop
Warehouse
Inspection Dept.
Packing & Delivery
Customized colorful box
Independent small package
Tube packaging
Delivery
Wooden case
Cartons
Main Products
Certifications
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.We support video see factory in this serious condition.
Q: How long is your delivery time?
A: Generally it is 1~3 days if the goods are in stock. or it is 7-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
